Plywood Machine : Knife Grinder
This machine mainly grind all type of long knives.
Max.Grinding Length : 1500 MM
Reciprocating Speed of Grinding Speed
All our plywood machines can be customized according to your production requirement.
Cutter Grinder /
4 Feet Cutter Grinder with Electromagnetic CNC
Expected Delivery in 4-10 Days
1.High degree of automation, saving labor.
2.Precise and careful grinding.
3.The worktable use the electro magnetic chuck. And very convenience to clamp knife. The worktable is easy to adjust the angle by worm gear.
4.The blade can rotate 0-90 degrees for electromagnetic absorption, and the grinding head is equipped with a centralized oil supply device.
| Configure | ||
| NAME | UNIT | PARAMETER |
| Max.Grinding Length | MM | 1500 |
| Area of Working Bench | MM | 1500*180(200) |
| Adjustable Angle of Operating Cutter Table | MM | ±90º |
| Power of Grinding Head Motor | MM | 4 |
| Total Power | MM | 6.5/5.5 |
| Reciprocating Speed of Grinding Speed | MM/MIN | 0-20 |
| Machine size | MM | 4000*1500*1500 |
| Machine Weight | KG | 2000 |
